Carrillo SC7467-6 Forged Piston Set Toyota 2JZ-GTE 86.5mm 9.5:1 Compression

The Carrillo SC7467-6 is a high-performance forged piston and ring kit engineered specifically for the Toyota 2JZ-GTE inline-6 twin-turbocharged engine. This complete piston set features an 86.5mm bore size (+0.5mm oversize) with a 9.5:1 compression ratio, making it ideal for boosted applications including turbo, supercharger, and nitrous builds.

Key Specifications:

• Bore: 3.406 inches (86.5mm)
• Compression Ratio: 9.5:1
• Stroke: 86mm
• Compression Height: 1.338 inches
• Wrist Pin: 0.866 inch diameter x 2.250 inch length
• Ring Thickness: 1.0mm x 1.2mm x 2.8mm
• Dish Height: -6.02mm

Premium Construction:

• Manufactured from high-strength 2618-T61 aluminum alloy forgings for excellent durability under high heat and cylinder pressure
• Fully CNC-machined and balanced to within +/- 1 gram for precise weight matching
• Deep valve reliefs designed to accommodate oversized valves and high-lift camshafts
• Custom skirt cam and barrel designs optimized for maximum performance
• Full radiused dome design for improved combustion efficiency

Complete Kit Includes:

• High-performance piston rings matched to piston design
• 5100 chromoly wrist pins chamfered for wire locks
• Pin locks and fitting hardware

CP-Carrillo pistons are engineered through extensive research and development with support from top motorsport teams. Each piston undergoes demanding quality control in their climate-controlled inspection facility using computerized electronic equipment. The 86.5mm bore size provides optimal performance for mildly overbored 2JZ-GTE engines, while the 9.5:1 compression ratio delivers an excellent balance of power and boost compatibility for street and track applications.
