Carrillo SC7463-6 Forged Piston and Ring Set 86mm 9:1 CR Toyota 2JZ-GTE

The Carrillo SC7463-6 is a premium forged aluminum piston and ring set engineered specifically for the Toyota 2JZ-GTE engine. This complete 6-cylinder kit features precision-machined pistons with an 86mm (3.386 inch) bore diameter and a 9:1 compression ratio, making it an ideal choice for turbocharged and high-performance applications.

Key Specifications:

• Bore: 86.0mm (3.386 inches) - Standard size
• Compression Height: 1.338 inches
• Compression Ratio: 9.0:1
• Stroke: 86mm
• Rod Length: 142mm
• Dish Volume: -8.8cc
• Wrist Pin Diameter: 22mm (0.886 inches)
• Ring Thickness: 1.0mm x 1.2mm x 2.8mm
• Material: High-strength forged aluminum

Premium Features:

• Fully CNC-machined and balanced to within +/- 1 gram for perfect uniformity
• Dish-style piston crown with deep four-valve reliefs for high-lift camshaft compatibility
• Accumulator groove to reduce ring flutter and improve sealing
• Anti-detonation grooves for enhanced durability under boost
• Double pin oilers for improved wrist pin lubrication
• Custom cam and barrel skirt design for optimized piston-to-wall clearance
• Complete kit includes pistons, rings, wrist pins, and retainers

Manufactured in Irvine, California using cutting-edge 5-axis CNC machining technology, CP-Carrillo pistons are engineered for maximum power and reliability in demanding high-performance and racing applications. Each piston features proprietary design elements including the CP groove for constant pressure distribution and specialized coatings to reduce friction and increase durability.
