Carrillo SC7300-1 Forged Piston Nissan KA24E/KA24DE 89.5mm +0.5mm Overbore

The CP-Carrillo SC7300-1 is a high-performance forged piston designed for the Nissan KA24E and KA24DE 2.4L four-cylinder engine. This single piston features a 89.5mm (+0.5mm overbore) bore diameter and is built from high-strength aluminum forgings to deliver exceptional durability and power output. Compression ratios are 8.0:1 for the KA24E and 9.0:1 for the KA24DE.

Engineered with CP-Carrillo's precision CNC machining and dedicated forging process, this piston is compatible with turbocharger, supercharger, and nitrous oxide applications, making it a top choice for performance builds ranging from street use to all-out competition.

Key Specifications:

• Bore: 89.5mm (+0.5mm oversize)
• Stroke: 96mm
• Rod Length: 165mm
• Compression Height: 34.011mm (1.339 in.)
• Piston Head Volume: -20.2cc (dish)
• Compression Ratio: 8.0:1 (KA24E) / 9.0:1 (KA24DE)
• Piston Style: Dish, forged aluminum
• Sold individually (single piston)

Key Features:

• High-strength aluminum forgings for maximum durability
• Fully CNC-machined and balanced to within +/- 1 gram
• Deep valve reliefs accommodate high-lift camshafts and +1mm oversize valves
• Custom skirt cam and barrel design for optimized ring seal
• Accumulator groove reduces ring flutter and improves combustion seal
• Dual forced-feed pin oilers for enhanced wrist pin lubrication
• Pick-lock grooves for easy lock removal
• Wrist pins and pin fitting included at no additional cost
• Compatible with turbo, supercharger, and nitrous oxide applications

CP-Carrillo pistons are manufactured in the USA and undergo rigorous quality control inspection to ensure precise tolerances and consistent performance build after build.
