CP-Carrillo SC7127-4 Honda D16Z6 Forged Piston and Ring Kit 75mm Bore 10.5:1

The CP-Carrillo SC7127-4 is a complete forged piston and ring kit designed for the Honda D16Z6 engine.

Each piston is CNC-machined from high-strength aluminum forgings and balanced to within ±1 gram for superior rotating assembly consistency. The kit is compatible with turbo, supercharger, nitrous oxide, and naturally aspirated applications, offering broad versatility for performance engine builders.

Key Features:

• Bore: 75mm (2.953 in.)
• Stroke: 90.00mm
• Rod Length: 137.00mm
• Compression Height: 1.181 in.
• Compression Ratio: 10.5:1
• Dome Volume: +4.00cc
• Piston Style: Dish with four valve reliefs
• Material: High-strength forged aluminum
• Fully CNC-machined and balanced to ±1 gram
• Deep valve relief depth accommodates high-lift camshafts
• Custom skirt cam and barrel design
• Accumulator grooves for improved ring seal
• Double pin oilers with force-fed oil ring
• Pick lock grooves for easy lock removal
• Wrist pins included at no additional cost
• High-performance rings included
• Compatible with turbo, supercharger, nitrous, and N/A applications

CP-Carrillo engineers each piston using sophisticated computer modeling and 5-axis machining capability, ensuring optimal design and fitment. Produced in their Southern California facility, these pistons undergo multi-level quality inspection to meet the demands of both street performance enthusiasts and professional racers.
