Ferrea S10149-1 PAC Enhanced Dual Valve Spring for Honda/Acura K20

Manufacturer

Part Number

S10149-1
Black Friday Price

$41.11

Estimated ship date Monday, November 30

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Ferrea S10149-1 is a high-performance PAC Enhanced dual valve spring designed specifically for Honda and Acura K-series engines. This heavy-duty valve spring is engineered for extreme high-lift camshaft applications and high-pressure valvetrain systems, making it ideal for drag racing and high-horsepower turbocharged builds producing 1000+ horsepower.

Key Specifications:

  • Outer Diameter: 22.86mm (installed height) / 30.38mm (free length)
  • Inner Diameter: 16.86mm (installed height) / 22.86mm (free length)
  • Seat Pressure: 140 lbs @ 40mm
  • Open Pressure: 265 lbs @ 30mm
  • Coil Bind Pressure: 317 lbs @ 20mm
  • Maximum Recommended Lift: 0.787 inches (20mm)
  • Maximum Recommended RPM: 9500

Features:

  • Manufactured from premium grade chrome silicon steel alloy
  • Heat-treated and stress-relieved for extended service life
  • PAC Enhanced dual spring design for superior harmonic control
  • Designed for high spring pressure applications and extreme performance builds
  • Controls valve bounce and provides stability at high RPM operation

Application: Acura RSX 2.0L and Honda Civic K20 DOHC VTEC 16-valve engines (2001-2006 and later K-series applications).

Important Installation Notes: This valve spring requires Ferrea titanium retainer part #E11125 (or tool steel retainer #E20054), Ferrea seat locator #SL1136 (factory spring seat locator must be discarded), and Ferrea valve locks #K10034. Not compatible with factory spring seat locators in high-pressure applications.

This is a single valve spring. Complete engine builds require 16 springs total (8 intake, 8 exhaust). Sold individually for replacement or specialized applications.
