King 25AB414-101 Air Bump Stop Mounting Sleeve 2.5 Inch Diameter 1.5 Inch Stroke

The King 25AB414-101 is a weld-in mounting sleeve designed specifically for King 2.5 inch diameter air bump stops with 1.5 inch stroke. This precision-engineered component provides a secure and reliable mounting solution for off-road suspension systems.

Construction and Design:

• Manufactured from high-strength SAE 4130 chromoly steel for maximum durability
• Features .093 wall thickness tubing for robust strength-to-weight ratio
• Machined for clearance at the top end with laser-cut tops that are TIG-welded
• First 1.25 inches at the open end is machined to a smaller size for a snug fit on the bump stop
• Delivered raw (unfinished) for direct welding onto your chassis

Key Features:

• Unique design holds the bump stop around the entire outside diameter without crushing
• Locating pin registers into the top plate for precise alignment
• Bump stop's threaded boss bolts securely to the mounting sleeve
• Superior to pinch bolt designs that can crush and damage bump stops
• Compatible with King 2.5 inch air bump stops with 1.5 inch stroke

This mounting sleeve is ideal for custom off-road builds requiring reliable suspension bottoming control. Professional welding required for installation. Bump stop sold separately.
