GPI 16510001 M30 Mechanical Fuel Meter, Gallons, 5-30 GPM, 1" NPT

The GPI 16510001 M30 (model M30-G8N) is a mechanical fuel meter, also called a fuel flow meter or fuel transfer meter. It reads in gallons and measures fuel in the field. It is built for thin-viscosity petroleum fuels and for pump systems in the 5 to 30 GPM (19 to 114 L/min) flow range.

Key Features:

• Flow range of 5 to 30 GPM, accurate to within +/-2%
• 1" NPT inlet and outlet
• Four-digit display with batch total and cumulative total in gallons
• Twist knob reset
• Mechanical gears translate flow data from a nutating disk into calibrated units
• Magnetic drive replaces the driveshaft and seal, eliminating driveshaft leaks
• Durable aluminum housing
• Four-bolt connections let you mount the meter in several directions
• Attaches to the GPI G20 fuel transfer pump

This quick-fit modular meter is a simple way to add accurate fuel measurement to a compatible transfer pump system.
