MAHLE OX3614D Spin-On Engine Oil Filter with Overflow Valve M42x2

The MAHLE OX 361/4D (OX3614D) is a heavy-duty spin-on engine oil filter engineered to OEM specifications, featuring an M42x2 thread and a large-diameter housing designed for high-capacity engine applications. MAHLE is a world-leading OE supplier, and this filter delivers the same design, materials, and performance as the original equipment part it replaces.

The OX 361/4D is built with embossed and pleated filter media that provides superior dirt-holding capacity while maintaining low pressure drop across the filter, ensuring consistent oil flow and engine protection throughout the service interval.

Key Features:

• Filter Type: Spin-on — housing and element replaced as a single unit for clean, simple servicing
• Thread Size: M42x2 for secure, leak-free installation
• Outer Diameter: 136.0 mm (approx. 5.35 in)
• Height: 308.0 mm (approx. 12.13 in)
• Sealing Ring Diameter: 101.0 mm
• Overflow (Pressure Relief) Valve: Guarantees continuous oil supply during cold starts, high-viscosity conditions, or if service intervals are exceeded
• Non-Return Flow Valve: Prevents oil drain-back when the engine is off, ensuring immediate lubrication at startup
• Tightening Torque: 50 Nm
• Premium sealing technology for leak-free assembly and long service life
• Manufactured to OE design standards — same specs as factory-installed components

The MAHLE OX3614D is a direct-fit replacement oil filter for applications requiring the OX 361/4D specification. It reliably removes contaminants from the lubricant circuit to protect engine components, maintain oil quality, and preserve engine performance and efficiency.
