Carrillo SC7028-1 Forged Piston and Ring Set Honda D16Y7

The Carrillo SC7028-1 is a high-performance forged aluminum piston and ring set designed specifically for Honda D16Y7 engines. This individual piston features a 2.972-inch (75.5mm) bore with a +0.5mm oversize, making it an ideal choice for performance engine builds and rebuilds.

Key Specifications:

• Bore: 2.972 inches (75.5mm) - oversized (+0.5mm)
• Compression Height: 1.181 inches (29.997mm)
• Compression Ratio: 9.0:1
• Stroke: 90mm
• Rod Length: 137mm
• Pin Diameter: 19mm
• Piston Weight: 242 grams
• Dish Volume: -13.0cc with four valve reliefs
• Ring Thickness: 1.0mm x 1.2mm x 2.8mm

Premium Features:

• Forged from high-strength 2618 aluminum for exceptional durability
• Fully CNC-machined and balanced to +/-1 gram for precision performance
• Custom skirt cam and barrel design for reduced friction
• Deep valve relief depth accommodates high-lift camshafts
• Accumulator grooves for improved oil control
• High-performance piston rings included
• Wrist pin included at no additional cost
• Suitable for turbo, supercharger, and nitrous oxide applications

CP-Carrillo pistons are engineered using sophisticated computer modeling and manufactured with state-of-the-art 5-axis CNC machining at their Southern California facility. Each piston undergoes rigorous quality control in their climate-controlled inspection department to ensure it meets the exacting standards demanded by professional engine builders and performance enthusiasts. Made in the USA.
