Carrillo SC7299-1 Forged Piston for Nissan Bore - KA24E/KA24DE 89mm

The Carrillo SC7299-1 is a high-performance forged aluminum piston engineered for Nissan KA24E and KA24DE engines. Precision-machined using advanced 5-axis CNC equipment, this piston delivers the durability and performance demanded by turbo, supercharger, and nitrous oxide applications.

Key Specifications:

• Bore: 3.504 inches (89.0mm)
• Compression Height: 1.339 inches
• Compression Ratio: 8.0:1 (KA24E) / 9.0:1 (KA24DE)
• Pin Diameter: 0.827 inches (21mm)
• Piston Head Volume: +20.20cc dish design
• Stroke: 96.0mm
• Rod Length: 165.0mm

Features:

• High-strength forged aluminum construction for extreme durability
• Fully CNC-machined and balanced to +/-1 gram
• Dish design with no valve reliefs
• Complete with piston pin, rings, and retainers
• Premium ring package: 1.0mm steel top ring, 1.2mm cast iron second ring, 2.8mm oil ring
• Press-fit or floating wrist pin style
• Suitable for turbocharged, supercharged, and nitrous applications

CP-Carrillo pistons are designed using sophisticated computer modeling and manufactured in their state-of-the-art facility in Irvine, California. Each piston undergoes rigorous quality control in their climate-controlled inspection department to ensure consistent performance. This piston is sold individually and features the proven engineering that has made CP-Carrillo the choice of champions in professional motorsports.

Note: Sold individually. Four-cylinder engines require quantity of 4.
