CP-Carrillo SC7336-1 Forged Piston & Ring Set Nissan VG30DETT 88mm 8.5:1 Single

The CP-Carrillo SC7336-1 is a single forged aluminum piston and ring set engineered for the Nissan VG30DETT engine. Designed as a direct high-performance replacement, this piston features an 88.0mm (+1.0mm oversize) bore and an 8.5:1 compression ratio, making it well-suited for forced induction and high-output builds. The "-1" suffix denotes this is a single-piston unit — ideal for replacing an individual piston or building a custom quantity order.

Key Specifications:

• Bore: 88.0mm / 3.465 in. (+1.0mm oversize)
• Compression Ratio: 8.5:1
• Stroke: 83mm
• Rod Length: 154.2mm
• Compression Height: 32.004mm / 1.260 in.
• Pin Diameter: 22mm
• Ring Thickness: 1.5 x 1.5 x 2.8mm
• Piston Weight: 349 grams
• Dome/Dish Height: -9.6 (dish with four valve reliefs)
• Replacement Pin: 866-2250-15CP1C
• Replacement Rings: RS1116-3465-0

CP-Carrillo Features:

• High-strength forged aluminum construction with dedicated forgings per application
• Fully CNC-machined and balanced to ±1 gram
• Deep valve reliefs to accommodate high-lift camshafts and oversized valves
• Accumulator grooves for improved ring seal
• Dual forced-feed pin oilers for superior lubrication
• Pick lock grooves for easy lock removal
• Wrist pin and pin fitting included at no additional cost
• USA manufactured

CP-Carrillo pistons are the choice of professional race teams and performance engine builders worldwide. The SC7336-1 delivers the precision, strength, and consistency required for high-boost, high-revving, and competition-level VG30DETT builds.
