Oracle Lighting 3507-003 4-LED Omni-Directional Emergency Strobe Light - Red

The Oracle Lighting 3507-003 is a compact, self-contained 4-LED SMD Omni-Directional Emergency Strobe in Red. At only 7/8 inch in height, this ultra-low-profile strobe is engineered for applications where both size and light intensity are critical. A single 1-inch mounting hole is all that's needed for installation inside any headlight, cornering light, or tail light assembly — or it can be surface-mounted on the exterior of a vehicle.

With 10 selectable flash patterns, including synchronized alternating and synced multi-unit flashing, this strobe delivers professional-grade emergency signaling in a miniature package. No separate flashers, lamp drivers, ballasts, or power supplies are required — everything needed for operation is built in.

Key Features:

• 4-LED SMD omni-directional design mounts in any position or orientation
• 10 flash patterns including SOS, burst sequences, and steady-on modes
• Synchronized flashing support for use with multiple Oracle SMD strobes
• 10–16VDC operating voltage — compatible with standard 12V vehicle systems
• IP65-rated for dust and water resistance
• Meets SAE J1113-41 Class 5 electromagnetic compatibility standard
• No external drivers, ballasts, or flashers required
• Available in White, Blue, and Red
• 4-LED and 9-LED versions available

Dimensions:

• LED Unit: 1-1/2" W × 7/8" H
• Driver Module: 4-3/4" L × 15/16" W × 7/16" H
• Overall Wire Length: 160 inches (13.3 ft.)

Wiring Guide:

• Red Wire — Power (10–16VDC)
• Black Wire — Constant Ground
• White Wire — Sync wire for synchronizing multiple SMD Emergency Strobes
• Yellow Wire — Mode selector (requires a simple toggle switch)

Flash Mode Sequence:

• Steady On
• Mode Cycle
• SOS
• 2 Round Burst
• 3 Round Burst
• 4 Round Burst
• Fast Flash Steady
• Fast Flash Burst
• Fast Flash Burst + 12 SOS Flashes
• Fast Flash Burst + 6 SOS Flashes

Package Includes:

• 1 × LED Light with integrated driver module
• 2 × Mounting screws
• 1 × Gasket
