Bussmann AMI-100 Fast-Acting Stud Mount Fuse 100 Amp 32V

The Bussmann AMI-100 is a fast-acting, bolt-down automotive fuse designed for high-power distribution applications requiring reliable circuit protection. This 100-amp fuse is engineered for select late model vehicles and custom electrical systems using a compatible HMID fuse block.

Key Features:

• 100-amp current rating with 32V DC voltage rating
• Fast-acting fuse protection with 2000A interrupt rating at 32V DC
• Rugged tin-plated brass terminals for reliable connections
• Color-coded housing for easy amperage identification
• Bolt-down stud mount design with maximum torque of 35 in-lbs
• UL-rated 94V0 thermoplastic housing material
• Meets SAE J1171 (ignition protected) and ISO 8820-5 standards

The AMI series from Eaton's Bussmann division provides dependable circuit protection for automotive electrical systems. Requires a compatible Bussmann HMID fuse block (sold separately) for installation. Dimensions are approximately 41mm L x 12mm W x 6mm H.
