True Tech Ignition TH47T Throttle Position Sensor

The True Tech Ignition TH47T is a precision throttle position sensor designed for fuel injection and throttle body injection systems. This sensor monitors the throttle valve angle and transmits accurate position data to the engine control module for optimal fuel delivery and engine performance.

Key Features:

• Maintains specific installed outputs to match OE specifications rather than adjustable consolidated designs
• Circuits printed on flexible polyimide film or ceramic-based substrates for excellent dimensional stability
• Noble palladium, gold, and platinum alloys provide low contact resistance for extended service life
• Integral rotor bearings and return springs for easy installation
• Undergoes rigorous end-of-line testing with thousands of data points to validate output voltages
• 3-terminal connector design for reliable electrical connections

This TPS is engineered to prevent electrical performance drift and ensure trouble-free operation. Compatible with various GM applications including Buick, Cadillac, Chevrolet, GMC, Oldsmobile, and Pontiac vehicles from the late 1980s through mid-1990s.

Cross-Reference Numbers: SS10429, EC1033, 17080692, 17087654, 5S5037, 803148
