BorgWarner 177192 S200SX Turbine Housing 1.15 A/R T4 Twin Scroll

The BorgWarner 177192 is a genuine turbine housing designed for S200SX and S200SX-E series turbochargers. This high-quality cast iron housing features a 1.15 A/R ratio and is engineered to support performance applications in the 300-650 horsepower range.

Key Specifications:

• A/R Ratio: 1.15
• Turbine wheel outer diameter: 70mm (2.74 inches)
• Twin scroll divided volute design for improved exhaust pulse separation
• T4 inlet flange bolt pattern
• V-band outlet configuration
• Cast iron construction for durability and heat resistance

This turbine housing is compatible with BorgWarner AirWerks S200 super-core assemblies and is commonly used in John Deere 6068H applications. The twin scroll design provides improved turbo response and efficiency by keeping exhaust pulses separated. Mounting hardware, clamp plates, and cap screws are typically included with super-core purchases.

Cross Reference: Supersedes part number 172083. Compatible with BorgWarner turbocharger assemblies 177261, 177262, 177265, 172425, and 172450.
